◉ High Sensitivity
◉ Low power consumption
◉ High contact capacity 2A 30VDC
◉ Conforms to FCC Part 68 1500V Surge and Dielectric 1000VAC
◉ RoHS Compliant
As the professional manufacturer, we would like to provide you Ultra Compact Size Single Coil Latching Relay. And we will offer you the best after-sale service and timely delivery. Sincerely look forward to cooperating with you in the near future.
DIL pitch terminals. High sensitivity :0.14W or 0.10W nominal power.
Conforms to FCC Part 68 1.5kV surge and dielectric 1000VAC.
Monostable, single or double coil latching relay .
Application for telecommunication equipment, office equipment, security alarm systems, measuring instruments,medical monitoring equipment, audio visual equipment, flight simulator, sensor control.
Ordering Information
1 Part number:P
2 Operating function:
NIL: Single Side Stable;
L:1 Coil Latching; K:2 Coil Latching
3 Coil rated voltage(V):DC:3,4.5,5,6,9,12,24
4 Contact material:NIL: AgPd; W: AgNi
Contact Data
CAUTION:
Relays previously tested or used above 10mA resistive at 6V maximum DC or peak AC open circuit are not recommended for subsequent use in low level applications.
Coil Parameter
CAUTION:
1.The use of any coil voltage less than the rated coil voltage will compromise the operation of the relay.
2.Pickup and release(reset) voltage are for test purposes only and are not to be used as design criteria.
3.When latching relays are installed in equipment, the set and reset coil should not be powered simultaneously. Coil should not be pulsed with less than the nominal coil voltage and pulse width should be a minimum of three times the specified operate time of the relay. If these conditions are not followed, it is possible for the relay to be in the magne tically neutral position .
Characteristics
Electrostatic Capacitance
Between Open Contacts
Approx.0.4pF
Item4.41 of IEC 61810-7
Between Coil & Contacts
Approx.0.9pF
Item 4.41 of lEC 61810-7
Between Contact Poles
Approx.0.2pF
Item 4.41 of lEC 61810-7
Insulation Resistance
1000MΩ min(at 500VDC)
Item 4.11 of IEC 61810-7
Dielectric Strength
Between Open Contacts Between Coil & Contacts Between Contact Poles
1000VAC 1min
1000VAC 1min
1000VAC 1min
Item 4.9 of lEC 61810-7
Surge Withstand Voltage
Between Open Contacts Between Coil &Contacts Between Contact Poles
1500V
1500V
2500V
FCC68
Shock Resistance
Functional:490m/s² 11ms;
Destructive:980 m/s² 6ms
Item 4.26 of lEC 61810-7
Vibration Resistance
10Hz~55Hz Double amplitude
Functional: 3mm Destructive:5mm
Item 4.28 of lEC 61810-7
TerminalsStrength
5N
Item 4.24 of lEC 61810-7
Temperature Range
-40℃~70℃(-40° F~158° F)
Mass
Approx1.5g
Item 4.7 of lEC 61810-7
Safety Approvals
Dimensions
